Orbit Easy Dial 4-Station Indoor Irrigation Controller (Model 28964) – 24 VAC, Up to 6 Zones

Orbit Easy Dial 4-Station Indoor Irrigation Controller (Model 28964) provides a straightforward, dial-based approach to watering. It supports 24 VAC sprinkler and drip systems and can manage up to six zones, delivering reliable scheduling without apps or Wi‑Fi. The compact unit is designed for indoor installation in a dry, covered space such as a garage or utility room. For outdoor exposure, place it inside an Orbit 57095 outdoor cabinet with GFCI protection to keep wiring safe from the elements.

Smart scheduling with two programs

The controller features two independent programs, A and B, letting you tailor schedules for different types of zones. Each program offers four start times, enabling cycle-and-soak windows that help water soak into soil more evenly. An automatic “stacking” feature ensures overlapping runtimes run one valve at a time, reducing overwatering. The Budget dial adjusts all runtimes proportionally from 10% to 200%, so you can adapt to seasonal changes without reprogramming every station.

Manual control, rain delay, and expandability

Manual run mode makes it easy to test zones or perform targeted watering. A configurable Rain Delay lets you skip watering after rainfall. A relay switch supports an automatic rain and freeze sensor (sold separately). Note: Pump-start relays are not supported on this model.

What you’ll connect and how it works

Setup is straightforward: mount on a wall near a power outlet, connect the common wire to the C terminal, and attach zone wires to stations 1–6. The unit uses screw terminals to hold 18‑gauge irrigation wire. A 300 mA transformer powers one valve solenoid at a time, and the controller is compatible with 24 VAC valves from major brands such as Hunter, Rain Bird, and Toro.

Helpful tips

• If the display shows No AC, verify the transformer is plugged in and powered.
• Indoor placement protects electronics; for outdoor exposure, use the weatherproof cabinet.

Key benefits

• Simple dial operation with no apps or Wi-Fi to manage.
• Two programs with cycle-and-soak scheduling for efficient watering.
• Automatic zone stacking to avoid running multiple valves simultaneously.
• Flexible runtimes via Budget adjustment for seasonal needs.
