Orbit 57596 Easy Dial 6-Station Indoor Sprinkler Controller - 6 Zones

Simple, tactile control for reliable irrigation

The Orbit 57596 Easy Dial 6-Station Indoor Sprinkler Controller brings hands-on scheduling back to your yard. Designed for dry, indoor locations, it handles up to six zones on 24 VAC systems. With a compact, mechanical interface, you can set up watering patterns without relying on apps or Wi-Fi, making it a straightforward choice for homes that value reliability and ease of use.

Powered by a dedicated 300 mA transformer, this controller energizes one valve solenoid at a time, helping to keep power usage predictable while you manage irrigation across multiple zones. For outdoor exposure, you can house it within an Orbit 57095 outdoor cabinet with built-in GFCI protection, maintaining protection without sacrificing performance.

Two programs for flexible scheduling

Program A and Program B let you tailor schedules to different areas of your landscape. Each program includes four start times, enabling cycle-and-soak windows that support soil infiltration and reduce runoff when used thoughtfully. The controller automatically stacks overlapping runtimes so only one valve operates at any given moment, reducing interference and simplifying water management.

• Two independent programs with four start times each
• Cycle-and-soak windows promote better soil absorption
• Automatic zone stacking prevents simultaneous valve operation
• Budget dial scales all runtimes from 10% to 200% without reprogramming

Manual control, rain delay, and expandability

Need a quick test or a boost of water for a specific area? The Manual Run mode lets you target one zone, several zones, or all zones for a set duration. Rain Delay pauses scheduled watering during wet periods. A relay switch provides a pathway to add an optional rain or freeze sensor for smarter automation.

• Manual run mode for testing zones or supplemental watering
• Rain Delay to skip irrigation after rainfall
• Relay ready for optional rain/freeze sensor (sold separately)
• Indoor installation by design; outdoor use requires a weather-protected cabinet

Installation and compatibility

Install on an indoor wall near a power outlet. Connect the common wire to the C terminal and land each zone wire on stations 1–6. Screw terminals hold 18-gauge irrigation wire securely. The system is compatible with 24 VAC valves from major brands like Hunter, Rain Bird, and Toro. If the display shows "No AC," confirm the transformer is fully plugged in.

With its tactile dials and clear labeling, the Orbit Easy Dial controller offers a practical, maintenance-friendly option for multi-zone irrigation. It emphasizes dependable, consistent watering control that can adapt to different landscape needs, all without requiring a smartphone or internet connection.
