Orbit 55200 Pulse Pop-Up Sprinkler Head – 35 ft Throw, 20–360° Arc, Durable ABS/Steel

Overview

The Orbit 55200 Pulse Pop-Up Impact Sprinkler Head in black is engineered to keep landscapes lush even when faced with challenging water quality. A double-weighted impact arm promotes reliable operation under higher pressure, while a 3-inch pop-up height ensures the nozzle clears taller grasses. With a maximum throw of up to 35 feet and an adjustable arc from 20 to 360 degrees, you can tailor the spray to reach only your intended landscape areas and avoid hardscape surfaces. A low precipitation rate helps curb runoff on many soil types, and the pre-installed 3 GPM nozzle delivers a full-pattern precipitation of 0.18 inches per hour when spaced at 40-foot square patterns at 40 PSI.

In daily use, the Pulse design brings a measured, consistent spray that can be adapted to different yard layouts. The radius can be dialed down to 75 percent of the maximum distance, giving you tighter control when concentrating coverage in smaller zones. The can and riser are built from high-impact ABS, with stainless steel components for durability in outdoor environments. Arc adjustment stops make pattern setup quick and tool-free, while the trip pin lets you flip to a full pattern with ease. Both side and bottom inlets are 1/2-inch FPT, with a slotted plug sealing the inactive inlet for clean installs. The Pulse is compatible with pop-up rotors from Orbit, Hydro-Rain, and other major brands, and it can be paired with a smart controller like B-hyve for coordinated water use.

Key benefits

• Handles high-mineral content and reclaimed water without frequent clogging, thanks to a large nozzle orifice.
• Low precipitation rate (0.18 in/hr at 40 ft spacing, 40 PSI) helps minimize runoff and puddling.
• Arc is adjustable from 20 to 360 degrees; radius can be reduced to 75% for precise targeting.
• Sturdy construction blends ABS plastic with stainless steel components for durability in outdoor conditions.
• Dual inlet ports support different pipe depths; a slotted plug seals the unused inlet for neat installs.

Practical use cases

Ideal for landscapes where sprinklers must cover medium-sized areas with clear separation between heads. The 3-inch pop-up height helps clear tall vegetation, while the 35-foot throw suits mid-range layouts. Use it where you want to minimize excess water near hardscapes and driveways.

Installation and compatibility

The Pulse head ships with a pre-installed 3 GPM nozzle and is compatible with common irrigation setups. Simple arc stops and a radius adjustment screw let you shape the pattern without tools. Inlets are 1/2-inch FPT on both sides, with a slotted plug to seal the unused inlet. For water-conscious projects, pairing Orbit components with a smart controller like B-hyve can help coordinate schedules and optimize efficiency.

Operating pressure is typically 40 PSI, and outdoor use is specified for cold water only.
